Valve Bag Filling / Packers

Valve Bag Fillers/Packers

 Package Specifications:

  • Filling weight range: 10-50 kilograms.
  • Bag dimensions: pre-made bag, with side opening (valve) according to the volume and type of product to be filled.
  •

Standard specifications:

Filling System:

  • Tank capacity: 500 liters.
  • Tank is made of painted steel.
  • Auger feeder for weighing unit.
  • Double gate to feed weighing hopper.
  • One separate weighing unit for each filling head.
  • CE marked electronic digital weight control.
  • CE marked load cell.
  •

 Auger  specifications:

1.    Auger is fixed horizontally.

2.    Made of stainless steel.

3.    With a CE marked motor to ensure the movement of products into the bag.

4.    With a special hole for the valve bags required.

Bag feeding mechanism:

  • Bags are fed to filling nozzle manually.
  • An automatic command is issued leading a pneumatic mechanism hold the bag.
  • After discharging product into bag according to the required weight, the bag is pushed off the filling nozzle manually (a special automatic pusher is available on request).

 Machine Production capacity:

1.    6 bags per minute approximately, for each machine, based on 25 k.g. bags,

2.    provided that the product is dry & has no tendency to agglomerate.
