Manual Wrapping Machine Welding and Heat Shrink (FM77 EVO)

Manual Wrapping Machine Welding and Heat Shrink (FM77 EVO)



o  Standard sealing bar cooling: optimal sealing

o  Immediate shrink fan stop: reduced loss of hot air and resulting energy savings, a benefit for the operator

o  Innovative upper hood fastening: simplified maintenance and enhanced stability

o  Sealing blades safety control: enhanced machine safety

o  Support with larger reel diameter (300 mm): suitable for micro-punched film to pack bread

o  Packaging plate separated from the reel support: suitable to package even very small products with the same film reel

o  Innovative micro-perforator: continuous and optimal perforation

o  New ultra-flat tactile membrane: waterproof and with intuitive graphics not associated with the board

o  3-digit display: visibility and comprehensive information

o  Board with 10 programs to meet any programming need

o  Piece counter included: a more exhaustive supply of equipment

o  Board assess through a door: easier maintenance from the front

o  Longer screened plate: chamber opening flap protection

o  Boosted fan motor: superior shrinking performance

o  Added safety thermostat installed directly on the resistor of the heat chamber: greater safety for the machine

o  Glue-less neoprene rubber support: easy to replace, does not require the use of glue.

o  Hourly output: from 0 to 300

o  Available dimensions of sealing bars: 590 x 840 mm

o  Maximum product size: 200 x 500 x 800 mm

o  Maximum reel dimensions x Ø (Length): 800 x 300 Ø mm

o  Work surface height: 940 mm

o  Machine dimensions (hood open): 1480 x 1000 x 1950 mm

o  Machine dimensions (closed hood): 1180 x 1000 x 1950 mm

o  Weight (net/gross): 220/272 kilograms
